Product Description

Drive-in Rack System
Drive-in Rack Overview
It is suitable for storing large quantity of goods with less types, goods of batched working and small range of selection. The goods are stored on the support guide rail with the pallet one after another in the direction of depth, increasing the storage density and space availability. It is quite convenient for fork truck drives into lane directly to store or take out the goods.
Drive-in Rack View 1
Drive-in Rack View 2
Drive-in Rack View 3
Technical Specifications
Loading Weight 800~1000kg / pallet
Dimensions Height: 1500-8000mm | Width/Depth: 1000-1500mm | Length: 1500-3200mm
(Special sizes available to specific storage needs)
Main Parts Specs Upright section: 90*65, 120*65 (1.5mm - 2.0mm)
Beam Section: Box beam 80*45 / 100*45 / 120*45 / 140*45 / 160*45 (1.0 - 1.5mm)
Material High-quality cold rolled steel Q235
Components Horizontal & diagonal braces, upright footplates, safety locking pins, bolts & nuts, anchors
Packaging Air bubble pack, PE stretch film for scratch protection
Key Features
◈ Large loading capability: 1000KG-2000KG per pallet.
◈ Forklifts can drive directly into channels to fetch pallets.
◈ Low capital cost using conventional handling equipment.
◈ Extremely high warehouse utility ratio.
◈ Supports First-In-First-Out (FIFO) or First-In-Last-Out (FILO).
◈ Structural steel construction for maximum durability.
◈ Flexible configuration: 2-5 pallets deep and 2-5 levels high.
◈ High-quality powder coating finish in various colors.
Beam Loading Capacity & Structural Details
Beam Capacity Chart Loading Specs
Entry Configuration Types
Single Entry Rack
Single Entry Racks

Lift trucks can enter the rack from only one side.

Double Entry Rack
Double Entry Racks

Lift trucks can enter from both sides. The center is stabilized by a beam.

Structural Diagram
Product Overviews
Installation 1
Installation 2
Installation 3
Finished Project 1
Finished Project 2
Finished Project 3
Other Hot Sale Solutions
Heavy Duty Racking
Heavy Duty Pallet Racking
Medium Duty Rack
Medium Duty Rack
Mould Rack
Mould Rack
Cantilever Rack
Cantilever Rack
Mezzanine Floor
Mezzanine Floor
Wire Mesh Container
Wire Mesh Container
Frequently Asked Questions
1. Are you a manufacturing or trading company?
We are a professional racking manufacturer specializing in industrial storage solutions.
2. What material is used for the racks?
Our primary material is Q235B high-quality cold rolled steel, known for its strength and durability.
3. What is the typical delivery time?
Generally, it takes less than 15 workdays. This can vary depending on the order quantity and specific shelving design.
4. What are your payment terms?
We require a 30% T/T down payment and the remaining 70% T/T before delivery.
5. How can I get a quick quotation for my racking project?
Please provide the rack size (Length*Depth*Height), number of layers per set, load capacity per beam layer, and total quantity.
6. How do you handle quality control?
Quality is our priority. Our factory holds ISO 9001 certifications to ensure all products meet international standards.
