Heavy duty rack features a hooking structure, making it exceptionally easy to dismount and install. The height can be adjusted in increments of 75mm based on cargo requirements, with a robust loading capacity of 800-3000kg per layer.
🔹 Versatile Boards: Choose from steel plate, wood plate, or MDF layer boards.
🔹 Ideal Storage: Perfect for small and medium-sized warehouses due to its convenient access and appropriate height.
| Raw Material | High-Quality Q235 Cold rolled steel |
| Standard Colors | Upright frame: Blue; Beam: Orange (Customizable) |
| Standard Size | L2300*D1000*H4500 mm (Customizable upon request) |
| Height Range | 1500-8000mm |
| Width/Depth | 400-1500mm |
| Length | 1500-3200mm |
| Upright Section | 80*60, 90*65, 100*70, 120*95 mm (Thickness 1.5-2.5mm) |
| Loading Capacity | 1000~6000kgs (2200~13200lbs) |
| Beam Section | 80*45, 100*45, 120*45, 140*45, 160*45, 180*45 mm |
| Surface Treatment | Professional Powder Coated |
| Packaging | Air bubble film, Wooden Case, etc. |
