| Standards Size | Layer | Loading Weight | Beam(mm) | Upright(mm) | Thickness of Board(mm) |
|---|---|---|---|---|---|
| L2000*D600*H2000 | 4 | 200~300kg/layer | 60*40*1.2 | 60*50*1.2 | 0.5 |
| L2000*D600*H2000 | 4 | 400~500kg/layer | 60*40*1.5 | 60*50*1.5 | 0.7 |
| Product Name | Medium Duty Rack/Shelf |
| Material | High-Quality Q235 Colded-Coll Steel |
| Loading Capacity | 200~500kgs/level |
| Thickness | Upright: 60*40*1.0/1.2/1.5mm; Beam: 60*40/80*40*1.0/1.2/1.5mm; Steel: 0.5/0.6/0.7mm |
| Color | Upright: Blue, Beam: Orange, Steel: Gray white (Customizable) |
| Surface Treatment | Electrostatic Spray Surface |
| Packing Term | Air bubble, Carton, Wooden Case |
| Warranty | 10 Years |
| Certification | SGS |
| Medium Duty Rack Specs | |
| Size | L2000*D600*H2000mm |
| Loading | 300kg/layer |
| Material | Upright:60*50*1.0, Beam:60*40*1.2, Steel:0.5mm |
| Surface | Powder Coating |
Beam & Upright Connect
Diagonal & Horizontal Bracing
Steel Board Section
